Electromagnetic Vibrating Feeder

Electromagnetic Vibrating Feeder is supplied directly by EPIC Factory in China. The GZ series is widely used in mining, metallurgy, construction, chemical, and other industries to transport bulk materials from storage bins or hoppers to receiving devices, such as belt conveyors, bucket elevators, screening equipment, and crushers. It is also suitable for automatic batching, quantitative packaging, and production automation, improving production line efficiency and stability.

Core Features and Advantages

l High Efficiency and Stability: Electromagnetic vibration ensures continuous and uniform feeding, reducing downtime.

l Energy-Saving and Durable: Constructed with wear-resistant materials and high-strength spring steel for long service life.

l Easy Operation: Compact structure allows flexible installation in different production environments.

l Adjustable Control: Vibration amplitude can be adjusted to meet varying material and process requirements.

Product Parameter

Model	Slot specification			Feed size (mm)	Double amplitude (mm)	Voltage (V)	Power (Kw)	Feed volume(th)		(mm)
	W(mm)	D(mm)	H(mm)					horizontal	-10°
GZ-01	600	200	100	50	1.75	220	0.06	5	7	910x376x485
GZ-02	800	300	120	50	1.75	220	0.15	10	14	1175x506x600
GZ-03	900	400	150	75	1.75	220	0.2	25	35	1325x574x675
GZ-04	1100	500	200	100	1.75	220	0.45	50	70	1615x762x814
GZ-05	1200	700	250	150	1.75	220	0.65	100	140	1815x840x980
GZ-06	1600	900	250	200	1.5	380	1.5	150	210	2410x1092x1530
GZ-07	1800	1100	250	250	1.5	380	3.0	250	350	2800x1332x1710
GZ-08	2200	1300	300	300	1.5	380	4.0	400	560	3302x1556x1995
GZ-09	2400	1500	300	350	1.5	380	5.5	600	840	3515x1176x2200
GZ-10	2500	1800	375	500	1.5	380	4x2	750	1050	3630x2500x2235
GZ-11	2800	2000	375	500	1.5	380	5.5×2	1000	1400	4060x2640x2310

All technical parameters of the EPIC Electromagnetic Vibrating Feeder strictly follow the official EPIC website for the GZ series, with consistent units and dimensions.

Operating Instructions

1. Installation Preparation

l Ensure the installation surface is level, stable, and strong enough to support the equipment, avoiding vibration misalignment or material accumulation.

l Check foundation bolts for tightness to prevent loosening or tilting during operation.

l Verify the power supply, voltage, and grounding are safe and compliant with equipment specifications.

2. Testing and Start-Up

l Run the feeder empty for 3–5 minutes during initial start-up to check for uniform vibration and unusual noise or friction.

l Adjust amplitude and feed rate according to material properties and production requirements to achieve smooth and continuous feeding.

l Fine-tune vibration and feed intervals for different material densities, particle sizes, or moisture content to optimize performance.

3. Production Operation

l Evenly load materials into the hopper or bin to avoid localized accumulation and uneven feeding.

l Integrate with belt conveyors, crushers, and screening equipment for automated and continuous material feeding.

l During long-term operation, periodically check the feed status and adjust amplitude or clear the feeder if needed to maintain smooth production.

4. Routine Maintenance

l Regularly inspect the electromagnetic system, spring components, and connection bolts to ensure there is no loosening, wear, or abnormal vibration.

l Clean the feeder tray and vibrating parts to remove dust, debris, or residual material to prevent clogging or wear.

l Replace wear-prone components, such as springs and liners, according to production frequency to extend equipment lifespan.

l Stop the EPIC Electromagnetic Vibrating Feeder immediately if abnormal vibration, excessive noise, or high motor temperature occurs.

5. Safety Guidelines

l Operators should wear protective gloves, goggles, and other safety equipment to avoid contact with vibrating parts.

l Never overload the feeder, as this can damage the equipment or affect feed uniformity.

l Electrical components should be maintained by professionals to ensure safe operation.

Following these steps ensures continuous, uniform feeding and reliable operation, adapting to various materials and production environments.

Why Choose EPIC

l Quality Assurance: Manufactured by EPIC factory with one-year warranty and durable key components.

l Professional Technical Support: Provides guidance and training to help enterprises operate efficiently.

l Fast Response Service: On-site installation, commissioning, and maintenance support.

l Flexible Custom Solutions: Model and configuration adjustments available to meet specific production requirements.

FAQ

Q: What materials can the product handle?

A:The Electromagnetic Vibrating Feeder can handle bulk materials such as sand, ore, coal, metallurgical blocks, and chemical granules, especially suitable for fragile or high-wear materials, ensuring continuous and uniform feeding.

Q: How is the feeding capacity adjusted?

A: By adjusting the vibration amplitude and frequency, the material flow can be precisely controlled to meet different production process requirements.

Q: Is installation complicated?

A: The modular design makes installation simple. Just ensure level support and a stable foundation to quickly integrate it into the production line.

Q: Are maintenance costs high?

A: Key components are made of high-wear materials, and routine maintenance only requires cleaning the electromagnetic system and checking springs, resulting in low costs.

Q: Is the electromagnetic vibrator safe and reliable?

A: Equipped with overload protection and temperature control, the vibrator ensures safe and stable long-term operation, minimizing the risk of failure.
