Symons Cone Crusher

Symons Cone Crusher from supplier EPIC delivers high-capacity, intelligent crushing solutions for granite, basalt, limestone, iron ore, and other hard materials. With advanced automation, ultra-heavy frame, and optimized crushing surface, this professional manufacturer ensures higher efficiency, lower operational costs, and reliable maintenance, making it a preferred choice for global mineral processing projects.

Send Inquiry

Product Description

EPIC Symons Cone Crusher supplies from a Professional Manufacturer integrates mechanical, hydraulic, electrical, automation, and intelligent control technologies to provides high-quality crushing equipment with stable performance, reliable quality, and cost-effective solutions.. Designed to handle a wide range of materials, including hard rocks, ores, and construction aggregates, ensuring uniform product size and high output capacity.

Specifications

Model﹠specification	Breakingdiameter(mm)	Cavitytype	Size of feed port(mm)		The smallestDischarge outlet(mm)	Electric motor		Overall weight(excludingmotor)	Dischargeoutlet size(mm)	Capacity
Model﹠specification	Breakingdiameter(mm)	Cavitytype	Closing slde	Opening side	The smallestDischarge outlet(mm)	Model	Power(kw)	Overall weight(excludingmotor)	Dischargeoutlet size(mm)	Capacity
PYS-B0910	3(900)	Thin type	83	102	10	Y315S-6	75	14.5	10—22	55-100
PYS-B0917		Coarse type	159	175	13				18—38	55-185
PYS-B0918		Extra thick	163	178	25				25—38	120-185
PYS-B1313	4 1/4-1295	Thin type	109	137	13	JS126-6	155	26.5	13—31	125-210
PYS-B1321		Medium	188	210	16				16—38	140-285
PYS-B1324		Coarse type	216	241	19				19—51	180-385
PYS-B1325		Extra thick	238	259	25				25—51	250-400
PYS-B1620	5 1/2-1676	Thin type	188	209	16	JS136-6	240	49.6	16—38	205-365
PYS-B1624		Medium	213	241	22				22—51	275-465
PYS-B1626		Coarse type	241	268	25				25—64	320-700
PYS-B1636		Extra thick	331	368	38				38—64	465-755
PYS-BC2117	7 HDExtra Heavy-2134	Thin type	253	278	19	Y450-6	400	105	19—38	410-805
PYS-BC2133		Medium	303	334	16				25—51	560-1100
PYS-BC2136		Coarse type	334	369	31				31—64	860-1405
PYS-BC2146		Extra thick	425	460	38				38—68	960-1500
PYS-B2530	8 1/2HD-2590	Thin type	275	300	19	Y5602-12	560	135	19—38	710-1250
PYS-B2535		Medium	320	350	25				25—51	1050-1960
PYS-B2541		Coarse type	375	410	31				31—64	1250-2560
PYS-B2548		Extra thick	445	480	38				38—64	1450-2600
PYS-D0904	3(900)	Thin type	13	41	3	Y315S-6	75	15	3—13	30-105
PYS-D0906		Coarse type	33	61	3				3—16	30-120
PYS-D0907		Extra thick	51	76	6				6—19	60-145
PYS-D1306	4 1/4-1295	Thin type	29	64	3	JS126-6	155	27	3—16	35-185
PYS-D1308		Medium	54	89	6				6—16	80-185
PYS-D1310		Coarse type	70	105	10				10—25	115-255
PYS-D1313		Extra thick	98	133	16				19—25	225-265
PYS-D1607	5 1/2-1676	Thin type	35	70	5	JS136-6	240	49.7	5—13	105-240
PYS-D1608		Medium	54	89	6				6—19	140-315
PYS-D1613		Coarse type	98	133	10				10—25	205-375
PYS-D1614		Extra thick	117	158	13				13—28	285-375
PYS-DC2110	7HDExtra Heavy-2134	Thin type	51	105	5	Y450-6	400	105	5—16	200-455
PYS-DC2113		Medium	95	132	10				10—19	460-560
PYS-DC2117		Coarse type	172	178	13				13—22	490-660
PYS-DC2120		Extra thick	152	203	16				16—25	565-730
PYS-D2512	8 1/2HD-2590	Thin type	60	120	10	Y5602-12	560	135	5—16	550-670
PYS-D2515		Medium	100	150	13				10—19	660-820
PYS-D2519		Coarse type	130	190	16				13—22	760-1050
PYS-D2522		Extra thick	160	220	19				16—25	910-1290

What Are the Core Functions and Features of Symons?

· High crushing efficiency with adjustable discharge size of Symons Cone Crusher for diverse applications.

· Durable wear-resistant components including mantle, concave, and bowl liner.

· Compact structure for easy installation and reduced footprint.

· Smooth material flow ensures minimal blockage and reduced downtime.

· Advanced design ensures low vibration and energy-efficient operation.

Application

· Mining industry: Iron ore, copper ore, gold ore, manganese ore.

· Construction & aggregates: Limestone, granite, basalt, gravel production.

· Cement & chemical industry: Crushing raw materials and secondary reduction.

· Quarrying operations: High-capacity production of uniform aggregates.

The Main Maintenance and Wear Parts

Part	Description	Recommended Maintenance
Mantle	Main wear-resistant cone surface	Check weekly for wear, replace every 6–12 months depending on usage
Concave/Bowl Liner	Outer liner of the crushing cavity	Inspect monthly, replace when wear exceeds 10–15%
Bowl Adjustment Ring	Controls discharge size	Inspect quarterly, lubricate and adjust as needed
Main Shaft & Bearings	Supports crushing head rotation	Check alignment and lubrication weekly
Lubrication System	Ensures smooth operation	Replace oil every 3–6 months

Regular maintenance ensures the Symons Cone Crusher operates efficiently with reduced downtime and extended service life.

How Does EPIC Improve Production Efficiency?

· Stable Output: Uniform product size reduces screening requirements.

· High Throughput: Optimized crushing chamber design increases production capacity.

· Energy Efficiency: Advanced motor and drive system reduce electricity consumption.

· Reduced Downtime: Easy access to wear parts ensures faster maintenance.

Customers Support

· Pre-sale consultation and process design tailored to customer’s materials.

· On-site installation and commissioning services to ensure smooth startup.

· Training for operators and maintenance teams for long-term reliability.

· Worldwide after-sales support with spare parts availability.

· Customized solutions for production optimization and cost reduction.

What Makes EPIC Stand Out?

· Higher crushing efficiency and more uniform product size than conventional crushers.

· Wider range of models to accommodate various feed sizes and capacities.

· Lower operating costs with energy-saving motor designs.

· Robust structure ensures stable operation under heavy loads.

· Easy maintenance and readily available spare parts worldwide.

EPIC Symons Cone Crusher is your reliable solution for high-efficiency crushing with low operational costs, wide application, and excellent service support. By choosing EPIC, you gain not only a premium crushing machine but also a trusted global partner for mineral processing projects.
